点击图片查看原图四缸发动机六轴机器人柔性清洗机
Flexible cleaning machine for six axis robot
| 主要功能参数 | Main function parameters |
| 对应工件:缸体、缸盖、变速壳体、阀体等 | Corresponding workpieces: cylinder block, cylinder head, gearbox housing ralve body and so on |
| 工件材质:铝铁部件均可 | Workpiece material: aluminum parts are all adoptable |
| 生产节拍:50秒以上 | Cycle time: 50 seconds or more |
| 清洗压力:05-50MPa | Cleaning pressure: 0. 5-50mpa |
| 机器人数:单台、双台、多台同时 | Number of robots: single, double and multiple units |
| 输送方式:六轴机器人持工件形式 | Transportation: six-axis robot with workpieces |
| 清洗方式;紊流、定点、高压、毛刷去毛刺 | Cleaning methods: flowing water, fixed-point, high-pressure, brush to deburr |
| 去毛剩式:主油路插入毛刷、平面毛刷、高压水 | Deburring methods: brush inserted into the main oil line, plane brush, high pressure water |
| 干燥方式:压缩空气吹干、真空干燥 | Drying methods: compressed air drying, vacuum drying |
| 过滤方式:反冲洗自动排渣过滤、袋式过滤、纸带过滤 | Filter: back flushing automatic slag discharge filtration, bag filter, tape filter |
| 清洗精度:主油路1-5mg以下 | Cleaning accuracy: 1-5mg lower for main oil line |
| 过滤系统:1-3级过滤,最终过滤精度50-10u | Filtration system: grade 1-3 filtration with final filtration accuracy of 50-10u |
| 机器人品牌: FANUC、ABB、KUKA、STAUBLI | Robot brands: FANUC、ABB、KUKA、STAUBLI |
| 噪音:80db | Noise: 80db |
| 特点:易维护、柔性高、改造成本低 | Features: easy to be maintained, high flexibility, low transformation costs |
